wire joint 1 Pin I Shape 22-20AWG
wire joint 1 Pin I Shape 22-20AWG

1 Pin I Shape 22-20AWG

Customization Options:Package, Wire, Adapter and more

Brief Info

  • IP Rating: IP40
  • Wire Type: Strand & Solid
  • Contact Method: Insulation Displacement Connectors
  • Flame Retardant Rating: UL94v-1
  • Voltage & Current: 300V / 9A(Max Pin Can Bear)
  • Certification: CE, RoHs
  • share

Technical Specs

Item NO. Type Pin QTY. Workable Wire Voltage & Current Dimension Color Material IP Rating
WJ-I-1C I shape 1 wire 1 Pins 22~20 AWG / 0.34~0.54 mm² 300V / 9A (Max Pin Can Bear) 25*6.6*6.7mm Clear+Black PC & Copper IP40
WJ-I-1R I shape 1 wire 1 Pins 22~20 AWG / 0.34~0.54 mm² 300V / 9A (Max Pin Can Bear) 25*6.6*6.7mm Red+Black PC & Copper IP40

How To Use

Certification

Title Language Size Type
LCS191212060AR--Wire connectors--ROHS 2.0
English 1645kb pdf
LCS191212061AS-Wire connectors-EN 60998 report
English 2446kb pdf
LCS191212061AS-wire connectors-LVD
English 1388kb pdf

1 Pin I Shape 22-20AWG

Are you fed up with joining wires by peeling, twisting, and tapping them? The wire splicing connectors are an amazing technology that lets you join wires without any effort. Just insert the wire into the wire splicing connector and your connection is complete. There is no need to strip off or twist the wire to joint it with another wire. The I shape connector comes with two open ends. Insert one wire from one side and the second wire from the other side. Lock the connector and the wire joining is complete. The 1pin I shape connector is applicable with 22 to 20AWG wires. It is designed to join both solid and strand wires. The connector is made of PC and copper, and it is available in transparent and red colors. Just as other wire joining connectors, the 1pin I shape connector is also certified by CE and RoHS. The Onlumi customers from all over the world have been using this product with great confidence. The product is available in beautiful packaging. The company gives various packing options to customers to choose a packing as per their business need. The 1pin I shape connector is reasonably priced. Get a quote and buy this product at wholesale price.

Package Options

Boxes Face Seal Blister Hanging Head Clamshell Blister
