5mm 2 Pin Hippo-M for IP20 IP65 Single Color

Customization Options:Package, Wire, Adapter and more

Brief Info

  • Types: Strip to wire, Strip to Power, Strip to Strip Joint, Strip to Strip Bridge
  • Applicable Strip: IP20 Non-waterproof / IP54 Singe Side Glue Cover
  • Workable PCB Type: Flexible
  • Workable Wire: 22~20 AWG/0.32~0.52 mm2
  • Certificate: CE,RoHS,Reach
  • share

Options

Model NO. Types Connective Position
OL11-SEN5XB-2 Strip to wire for IP20 Between strip and wire
OL11-SEN5BB-2 Strip to strip joint for IP20 Between two strips, without wires
OL11-SEN5XB-2W Strip to Power for IP20 One connector with 150mm 20AWG Black-Red wire
OL11-SEN5BXB-2W Strip to Strip bridge for IP20 Between two connector with 150mm 20AWG Black-Red wire



Technical Data

Part Num Type Voltage/Current Strip width Pin NO. Size Material Wire Spec Wire Fixed Color
SEN5XB-2 strip to wire 3~24V/3.5A 5mm 2 Pins 24.3*9.6*7.7mm Polycarbonate & Copper / no wire Black & Transparent
SEN5BB-2 strip to strip joint 3~24V/3.5A 5mm 2 Pins 19.6*9.6*7.7mm Polycarbonate & Copper / no wire Black & Transparent
SEN5XB-2W strip to power 3~24V/3.5A 5mm 2 Pins 24.3*9.6*7.7mm Polycarbonate & Copper & PVC 150mm 20AWG/0.52mm2 with wire Black & Transparent
SEN5BXB-2W strip to strip bridge 3~24V/3.5A 5mm 2 Pins 24.3*9.6*7.7mm Polycarbonate & Copper & PVC 150mm 20AWG/0.52mm2 with wire Black & Transparent

Strip to Wire

Strip to Strip Joint

How to Use

Certificates

Title Language Size Type
LCS210603087AR-Hippo-M LED Strip Connector-REACH 211
English 1498kb pdf
LCS210220025AR-Hippo-M Connector-ROHS 2.0
English 1377kb pdf

5mm 2 Pin Hippo-M for IP20 IP65

Are you looking for a high-density LED strip connector to have a versatile lighting system in your home? The Hippo series of connectors are among the most powerful and user-friendly connectors designed for 5mm IP20 and IP65 LED strips. Having a beautiful design ad color combination, the Hippo-M connector is a great option to extend your LED strip and to join it with power. There are two types of connectors: one to join strip to wire, and another to join two strips without wire. The polycarbonate, PVC, and copper-made connector is a great connective solution for non-waterproof LED strips.

The connector for joining a strip to wire or power has two pin poles. It comes with a 150mm 20AWG wire in black and red colors. These wires are customizable. Moreover, the adapter and packaging of the connector can also be customized as per customers’ requirements. The 2-Pin Hippo-M connector for a 5mm LED strip provides an effortless connective solution. It uses the piercing method to connect strips to power wires. You do not need to peel off or twist wires for a connection. Simply insert the wire into the connector and clamp the connector to complete the connection.

Package Options

Boxes Hanging Head Face Seal Blister Clamshell Blister
