Customizable Options:Whole Products and Packages Depending on MOQ
| Item NO. | Model | Product Picture |
| PIR-03 | 2.4G wireless PIR Sensor | |
 |
 |
 |
2.4GHz PIR Sensor
| Sensing Technology | PIR |
| Sensing Angle | 120° |
| Sensitivity Setup Option | 4 / 8 / 12 meters |
| Delay Time Setup Option | 3S/10S/30S/1M/3M/5M/10M/30M/60M |
| Power Method | CR123A Battery |
| Working Temperature | -20~45° C |
| Working Humidity | 0~80% |
| IP Rating | IP44 |
| Communication Protocol | 2.4GHz |
| Communication Distance | 150 meters without barriers, 10-30 meters with barriers |
| Network Scale | Can control unlimited plugs |
| Housing Material | Polycarbonate (PC)+ABS |
Dimensional Diagram
2.4GHz PIR Sensor
